| System | |
| Processor | Intel® Atom™ x5-Z8350: 2M Cache, up to 1.92 GHz |
| System Chipset | Intel x5-Z8350 |
| System Memory | 2GB / 4GB DDR3L RAM |
| Other | 802.11 b/g/n WiFi |
| Storage | |
| Storage | 32GB eMMC / 64GB eMMC |
| Panel | |
| LCD Size | 10.1" |
| Resolution | 1280x800 |
| Luminance | 350 |
| Viewing angle | 170° (H/V) |
| Touch Type | PCAP |
| I/O | |
| USB | 2 x USB 2.0 |
| External I/O Connector | 1 x RJ45 for RS232 or RS422 or RS485 2 x USB 2.0 Type A 1 x 10/100/1000 Ethernet 1 x 4-Pin 3.5mm Audio Jack |
| Internal I/O Connector | 1 x Touch Button interface 1 x eDP & Dual channel 24bit LVDS 1 x I2C interface for PCAP 5 x USB interface for PCAP, Camera and others 1 x Micro USB2.0 client (reserved) 1 x Micro SD connector 2 x LED Bar interface 1 x AMIC |
| Camera | 2.0MP Camera |
| Display | |
| Resolution | LVDS: Max. resolution 1280x800 @ 60Hz |
| Multiple Display | Windows support extended mode |
| Audio | |
| Speaker Output | 4Ω 2.0W/2.5W(MAX) |
| Ethernet | |
| Chipset | Realtek RTL8723BS |
| LAN Port | 1 x RJ45 |
| Mechanical & Environmental | |
| VESA | 75 x 75 |
| Power Requirement | DC Input, 12~24V |
| Power Type | DC jack or Powered LAN 802.3AT |
| Operating Temp | 0°C ~ 40°C |
| Storage Temp | -10°C ~ 60°C |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Dimension (L x W) | 270 x 193 x 28 mm |
| Weight | 1.1 kg |
| Certifications | |
| Certification Information | CE, FCC Class B |
| Software Support | |
| OS Information | Windows 10 IoT (64 bit), Android 5.1(64 bit) |
| Power Requirement | |
| Adapter | Input: 100~240 Vac/50~60 Hz Output: 60W Adapter (12V @ 5A Adapter) |
| Data Collection | |
| Camera | 2M pixel |
| NFC | NFC Reader |
| Wireless Communication | |
| WLAN | 802.11 b/g/n |
